CNS 410

CNS 410 material is CNS G3067 Stainless steel bars CNS G3076 Stainless steel wires CNS G3077 Stainless steel wire rods Stainless steel wire rods.

Chemical composition of CNS 410, CNS 410 mechanical properties, CNS 410 datasheet, CNS 410 equivalent grade, Heat treatment and temperature process of CNS 410.

Tags: 410,

CNS 410 property sheet

CNS 410 Spec.

CNS G3067
Stainless steel bars

CNS G3076
Stainless steel wires

CNS G3077
Stainless steel wire rods

Related Materials

A 955 XM-28 Grade 280

A 955 XM-28 Grade 40

A 955 XM-28 Grade 420

A 955 XM-28 Grade 520

Chemical Composition of CNS 410

C:	Max	0.15
Si:	Max	1.00
Mn:	Max	1.00
P:	Max	0.040
S:	Max	0.030
Ni:	Max	0.60
Cr:	11.50	13.50
Mo:	Max	Min

Mechanical Properties of CNS 410

R_p0.2 (MPa)	655 (≥)
R_m (MPa)	427 (≥)
AKV (J)	22
A (%)	21
Z (%)	44
Hardness	HBW 134

CNS 410 shape and dimensions

CNS 410 Round bar:	1mm-800mm
CNS 410 Square bar:	10mm * 10mm-600mm *600mm
CNS 410 Flat bar:	Thickness:8mm-800mm Width:10mm to 1500mm
CNS 410 Sheet or Plate:	Thickness:3mm-80mm Width:1.5mm to 1500mm
CNS 410 Strip or Coil:	Thickness:0.1mm-3mm Width:1.5mm-1500mm
CNS 410 Forgings:	Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes
