Cr2


Cr2 material is GB GB/T 1229-2000 Alloy tool steel Measuring tool cutting tool steel.

Chemical composition of Cr2, Cr2 mechanical properties, Cr2 datasheet, Cr2 equivalent grade, Heat treatment and temperature process of Cr2.


Cr2 property sheet

Cr2 Spec.

GB GB/T 1229-2000
Alloy tool steel

Chemical Composition of Cr2

C: 0.95 1.10
Si: Max 0.40
Mn: Max 0.40
Cr: 1.30 1.65

Mechanical Properties of Cr2

Rp0.2 (MPa) 637 (≥)
Rm (MPa) 578 (≥)
AKV (J) 42
A (%) 42
Z (%) 13
Hardness HBW 231

Cr2 shape and dimensions

Cr2 Round bar: 1mm-800mm
Cr2 Square bar: 10mm * 10mm-600mm *600mm
Cr2 Flat bar: Thickness:8mm-800mm Width:10mm to 1500mm
Cr2 Sheet or Plate: Thickness:3mm-80mm Width:1.5mm to 1500mm
Cr2 Strip or Coil: Thickness:0.1mm-3mm Width:1.5mm-1500mm
Cr2 Forgings: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes
