X2CrNiMo18-14-3


X2CrNiMo18-14-3 material is X2CrNiMo18-14-3.

Chemical composition of X2CrNiMo18-14-3, X2CrNiMo18-14-3 mechanical properties, X2CrNiMo18-14-3 datasheet, X2CrNiMo18-14-3 equivalent grade, Heat treatment and temperature process of X2CrNiMo18-14-3.


X2CrNiMo18-14-3 property sheet

X2CrNiMo18-14-3 Spec.

Chemical Composition of X2CrNiMo18-14-3

C: Max 0.030
Si: Max 1.00
Mn: Max 2.00
P: Max 0.045
S: Max 0.015②
Cr: 17.0 19.0
Ni: 12.5 15.0
Mo: 2.50 3.00
N: 0.11 Min

Mechanical Properties of X2CrNiMo18-14-3

Rp0.2 (MPa) 775 (≥)
Rm (MPa) 563 (≥)
AKV (J) 43
A (%) 24
Z (%) 13
Hardness HBW 213

X2CrNiMo18-14-3 shape and dimensions

X2CrNiMo18-14-3 Round bar: 1mm-800mm
X2CrNiMo18-14-3 Square bar: 10mm * 10mm-600mm *600mm
X2CrNiMo18-14-3 Flat bar: Thickness:8mm-800mm Width:10mm to 1500mm
X2CrNiMo18-14-3 Sheet or Plate: Thickness:3mm-80mm Width:1.5mm to 1500mm
X2CrNiMo18-14-3 Strip or Coil: Thickness:0.1mm-3mm Width:1.5mm-1500mm
X2CrNiMo18-14-3 Forgings: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes
